Frequency range
40Hz-20kHz in room response

Power handling
50-250 Watts RMS recommended amplifier power

Sensitivity
95dB for 2.83 volts at 1 metre

Impedance
8 Ohms

Configuration
2-way

Enclosure type
Bass reflex, front vented

Low frequency driver
Single 255mm (10”) paper cone driver. 50mm (2”) voice coil wound on high powered kapton former, with ventilated magnet assembly and copper shorting ring for low distortion

High frequency driver
26mm (1”) doped fabric dome with large roll surround. Ferro fluid cooled. Coupled to a Krix designed 90 x 40 short throw waveguide

Crossover point
1.8kHz

Input terminals
Gold plated binding posts

Cut-out dimensions
295mm high x 1045mm wide recommended

Dimensions
285mm high x 1035mm wide x 150mm deep cabinet367mm high x 1117mm wide x 2mm thick faceplate

Weight
23kg each

The Megaphonix In-Wall Centre is designed to be installed below televisions or non-acoustically transparent projector screens. Using high power handling and high sensitivity drivers, these speakers will deliver crystal clear dialogue and dynamic effects, for a real home cinema experience.

The 255mm bass driver has a 50mm voice coil and has been developed to offer low harmonic distortion, especially in the critical midband. The paper cone and surround of the bass driver have been developed to provide the smoothest possible response. The high frequency drive unit is a specially-damped, high power, 26mm doped fabric dome tweeter, and is coupled with Krix’s proprietary waveguide to provide consistently-maintained optimum dispersion of 90 degrees horizontal and 40 degrees vertical over the entire working bandwidth.

The combined high frequency response is exceptionally smooth and well controlled – a new benchmark in loudspeaker reproduction.

Finished with a powder coated steel front baffle for easy installation, the Megaphonix In-Wall Centre is the perfect answer for a concealed, horizontal installation while maintaining exceptional performance.

For the ultimate cinema experience at home, play it through Krix.
